EA9 Red Oxide Primer is a two-pack amine-adduct cured epoxy designed for use as a high-performance primer for many types of surfaces i.e. aluminium, galvanising, steelwork, concrete, GRP and phenolic sheeting. Nippon EA9 primer/finish systems have been extensively used for long-term corrosion of both ferrous and non-ferrous surfaces within the civil engineering and building industry, and as lining systems for potable water, chemical and fuel storage tanks, palm oil derivatives and vegetable oil.
Product Features:
• Good resistance to abrasion and mechanical damage
• Outstanding resistance to aqueous solutions and a wide range of industrial chemicals
• Excellent adhesion on correctly prepared surfaces
Coating System
Application
Coating System
| Steel, Galvanised, Aluminium and Stainless steel surface | ||
|---|---|---|
| Type | Product Name | No. of Coat(s) |
| Primer/Sealer | EA9 Red Oxide Primer | 1 coat |
| Topcoat | EA9 Finish HB | 2 - 3 coats |
Application Data
| Application | Brush, Spray, Roller |
| Thinning | Brush, roller: 10% by volume of SA-65 Thinner |
| Touch Dry/ Hard Dry | 1 - 2 hours / 4 - 5 hours |
| Recoating Interval | Minimum 16 hours |
| No. of Coat(s) | 1 - 2 coats |
| Theoretical Coverage | 8.3 m² per litre (for dry film thickness of 60 microns) 6.2 m² per litre (for dry film thickness of 80 microns) |
